Features:
1.PLC Controlled, equipped with piston pump filling system. Applicable for the liquid package.
2.Standard Features:It integrates metering, bag-making, packaging, sealing, printing and counting.
3.Standard positioning with servo film transporting system; stable for transporting film with two synchronous belts;
4.High automation with auto correction function.
5.Reasonable structure, convenient adjusting operation and maintenance.
6.It is equipped with advanced level switch and static eliminator
Packing speed | 50bags/min/lane | |||
Bag size | W:80*125mm (4-side sealing bag) | |||
The maximum width of packing film | 1080(Film width) | |||
Thickness of film | 0.06-0.11mm | |||
Bag making mode | four sides seal | |||
Range of measuring | 25-55g | |||
Air consumption | 200L/min; 0.7Mpa | |||
Power/voltage | 5.7 KW/380V, 50 Hz | |||
Dimension | 130cm×190cm×280cm | |||
Weight | 950kg | |||
