Doypack Premade Bag Powder Stand Up Pouch Packing Machine

,

Doypack Premade Bag Powder Stand Up Pouch Packing Machine

Main Features:
1) Automatic doypack packing machine adopt precision indexing device and PLC to control eachaction and working station to makesure the machine operates easily and does accurately.
2) The speed of this machine is adjusted by frequency conversion with the range, and the actual speed depends on type of products and pouch..
3) Automatic checking system can check bag situation, filling and sealing situation.The system shows 1.no bag feeding, no filling and no sealing. 2.no bag opening/opening error, no filling and no sealing 3.no filling, no sealing..
4) The product and pouch contact parts are adopted stainless steel and other advanced material to guarantee the hygiene of products.

Doypack Machine Technical Parameters
Model
D-150F
D-200F
D-250F
Bag width(mm)
100-150mm
140-200mm
170-250mm
Bag length(mm)
120-220mm
150-350mm
150-400mm
Measuring range
Max.800ml
Max.1200ml
Max.2000ml
Packing speed
30-60bag/min
Power supply
220V 50/60Hz
Machine size
1200*900*1300mm
1800*1200*1500mm
2100*1200*1500
